Key Features:

1. 2D Imaging Engine: Capable of scanning both 1D and 2D barcodes quickly and accurately.
2. Ergonomic Design: Comfortable for extended use, reducing operator fatigue.
3. IP52 Rating: Offers protection against dust and splashes, ensuring durability in various environments.
4. Multiple Connectivity Options: Supports USB, RS-232, and Bluetooth, making it flexible for different setups.
5. Omnidirectional Scanning: Scans barcodes from any angle for quicker, more efficient scanning.
6. High-performance DPM Scanning (for specific models): Some models can read direct part marks (DPMs), ideal for industrial settings.
7. Extended Range Models: Options for scanning barcodes at various distances, including high-density barcodes.
8. Rugged and Durable: Built to withstand drops, ensuring reliability in tough environments.
9. Multiple Configuration Options: Available in corded and cordless variants, providing flexibility in usage.

Primary Uses:

• Retail: For fast and accurate scanning of product barcodes during checkout.
• Healthcare: Used for scanning patient wristbands, medications, and other healthcare-related items.
• Manufacturing and Warehousing: Scans barcodes on products and parts, including DPMs in industrial environments.
• Logistics: Helps in inventory management and shipping/receiving processes.
• Field Service: Scanning barcodes for asset tracking or customer service in mobile or remote environments.

• Common Uses:

  • Retail: Streamlines point-of-sale transactions and inventory management.
  • Healthcare: Enhances patient identification and medication administration processes.
  • Light Industrial: Improves asset tracking and quality control procedures.


    Specifications

    Physical Characteristics

    Dimensions	Corded DS4608: 6.5 in H x 2.6 in W x 3.9 in D 16.5cm H x 6.7cm W x 9.8cm D Cordless DS4678: 6.6 in H x 2.6 in W x 4.2 in D 16.8cm H x 6.6cm W x 10.7cm D Standard Cradle: 2.8 in H x 3.3 in W x 8.3 in D 7.1cm H x 8.4cm W x 21.1cm D Presentation Cradle: 2.8 in H x 3.3 in W x 8.3 in D 7.1cm H x 8.4cm W x 21.1cm D
    Weight	Corded: 5.7 oz (161.9g) Cordless: 7.9 oz (225g) Standard Cradle: 7.1 oz (201.3g) Presentation Cradle: 6.5 oz (184.3g)
    Input Voltage Range	Corded: 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply Standard/Presentation Cradle: 4.7 to 5.5 VDC Host Powered; 10.8 to 13.2 VDC External Power Supply
    Operating Current at Nominal Voltage (5.0V)	Corded: 340 mA (typical) Standard/Presentation Cradle: 470 mA (typical) Standard USB; 743mA (typical) 12V
    Standby Current (Idle) at Nominal Voltage (5.0V)	Corded: 150 mA (typical)
    Color	Nova White (corded only), Twilight Black
    Supported Host Interfaces	USB Certified, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
    Keyboard Support	Supports over 90 international keyboards
    TAA Compliance	Trade Agreement Act Compliant
    Electronic Article Surveillance	Compatible with Checkpoint EAS deactivation system
    User Indicators	Direct Decode Indicator, Good Decode LEDs, Rear view LEDs, Beeper (adjustable tone and volume)

    Performance Characteristics

    Light Source	Aiming Pattern: circular 617nm amber LED
    Illumination	(2) 660nm red LEDs
    Imager Field of View	31.6° H x 22.6° V nominal
    Image Sensor	1280 x 800 pixels
    Minimum Print Contrast	15% minimum reflective difference
    Skew/Pitch/Roll Tolerance	+/- 60°, +/- 60°, 0°–360°

    Imaging Characteristics

    Graphics Format Support	Images can be exported as Bitmap, JPEG or TIFF
    Image Quality	96PPI on an A4 document (DS4600-SR)

    Symbol Decode Capability2

    1D	Code 39, Code 128, Code 93, Codabar/NW7, Code 1 1, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3of 5, GS1 DataBar, Base 32 (Italian Pharma)
    2D	PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Han Xin, Postal Codes, SecurPharm, DotCode, Dotted DataMatrix
    OCR	OCR-A, OCR-B, MICR, US Currency
    Minimum Element Resolution	Code 39–3.0 mil (DS4600-SR) DataMatrix–5.0 mil (DS4600-SR) Code 39–2.0 mil (DS4600-HD) DataMatrix–4.0 mil (DS4600-HD)

    User Environment

    Operating Temp.	+32.0F to +122.0F (0.0C to +50.0C)
    Storage Temp.	-40.0F to +158.0F (-40.0C to +70.0C)
    Humidity	5% to 95% RH, non-condensing
    Drop Specification	Designed to withstand multiple drops at 6.0 ft (1.8m) to concrete
    Tumble Specification	Designed to withstand 2,000 tumbles in 1.5 ft (0.5m) tumbler
    Sealing	IP52
    ESD	Scanner/Standard Cradle/Presentation Cradle: ESD per EN61000-4-2, +/-15 KV Air, +/-8 KV Direct, +/-8 KV Indirect
    Ambient Light Immunity	0 to 10,000 foot candles/0 to 107,000 Lux

    Radio Specifications (DS4678)

    Bluetooth Radio

    Standard Bluetooth Version 5.2 with BLE: Class 1 330 ft (100m) and Class 2 33 ft (10m), Serial Port and HID Profiles; adjustable power: Class 1: output power adjustable down from 2dbm in 8 steps; Class 2: output power adjustable down from 0dbm in 8 steps

    Battery (DS4678)

    Battery

    Type: Li-Ion with asset reporting Capacity: 2,500 mAh\ Number of scans from full charge: 50,0003 Charge times from empty to full: 2 hours 15 minutes over external 12V 4 hours 30 minutes over external 5V 3 hours over BC1.2 USB 7 hours 45 minutes over standard USB

    Utilities and Maintenance

    123Scan	Programs scanner parameters, upgrades firmware, provides scanned barcode data and prints reports. www.zebra.com/123Scan
    Scanner SDK	Generates a fully-featured scanner application, including documentation, drivers, test utilities and sample source code. www.zebra.com/windowssdk
    Scanner Management Service (SMS)	Remotely manages your Zebra scanner and queries its asset information. www.zebra.com/sms

    Regulatory

    Environmental	2011/65/EU and EN 50581:2012 and EN IEC 63000:2018
    Electrical Safety	UL 60950-1, second edition, CAN/CSA-C22.2 No. 60950-1-07. EN 60950-1:2006/A2:2013 IEC 60950-1:2005/A2:2013 IEC 62368-1 (ed.2); EN 62368-1:2014
    LED Safety	IEC 62471:2006 (Ed.1.0); EN 62471:2008
    EMI/RFI	FCC: 47 CFR Part 15, Subpart B, Class B; ICES-003 Issue 6, Class B; EN 55032, Class B; EN 55024 EN 55035; EN 60601-1-2:2015, IEC 60601-1-2:2014

    Accessories

    Gooseneck Intellistand, Cup, Standard Cradle, Presentation Cradle

    DS4600-SR/DL Decode Ranges (Typical)4

    Symbology/Resolution	Near/Far
    Code 39: 3 mil	2.2 in to 5.4 in (5.6cm to 13.7cm)
    Code 39: 5 mil	0.7 in to 11.0 in (1.8cm to 27.9cm)
    Code 39: 20 mil	0 in to 44.0 in (0cm to 111.8cm)
    Code 128: 5 mil	2.7 in to 5.4 in (6.9cm to 13.7cm)
    PDF 417: 6.7 mil	1.3 in to 10.0 in (3.3cm to 25.4cm)
    UPC: 13 mil (100%)	0 in to 28.0 in (0cm to 71.1cm)
    DataMatrix: 10 mil	1.0 in to 11.5 in (2.5cm to 29.2cm)
    QR: 20 mil	0 in to 17.5 in (0cm to 44.5cm)

    DS4600-HD/HL Decode Ranges (Typical)4DS4600-HD/HL Decode Ranges (Typical)4

    Symbology/Resolution	Near/Far
    Code 39: 3 mil	1.3 in to 6.0 in (3.3cm to 15.2cm)
    Code 39: 5 mil	0.1 in to 11.5 in (0.3cm to 29.2cm)
    Code 39: 20 mil	0.6 in to 29.0 Specifications Descriptions Latest Reviews No Review 0 5 stars - 0 4 stars - 0 3 stars - 0 2 stars - 0 1 star - 0 Login You May Also Like Barcode Scanner DS4678 Codeless Barcode Scanner ₹39,131.00 Barcode Scanner DS4678-DPE Cordless Barcode Scanner ₹50,556.00 Barcode Scanner DS4608-DPE Barcode Scanner ₹50,835.00 Barcode Scanner CS60 Barcode Scanner ₹43,614.00 Barcode Scanner DS8108 Barcode Scanner ₹33,645.00 Barcode Scanner DS8178 Cordless Barcode Scanner ₹31,859.00 Barcode Scanner DS2208 and DS2278 Barcode Scanners ₹35,956.00 Barcode Scanner LI4278 1D Barcode Scanner ₹35,585.00 Get 50% Discount. Lorem, ipsum dolor sit amet consectetur adipisicing elit. Exercitationem, facere nesciunt doloremque nobis debitis sint? Subscribe Your experience on this site will be improved by allowing cookies. Allow cookies
