Give your workers an instant productivity boost with the RS2100 Wearable Scanner — the smallest enterprise wearable scanner on the market. Your workers will want to wear the RS2100, thanks to its innovative back of hand design that delivers a new level of comfort and dexterity. The unique mount leaves the palm entirely unobstructed, providing complete freedom to handle items. The very low profile enables easy picking in tight spaces. And there’s nothing complicated about this wearable scanner: it’s simple to purchase, deploy, wear and manage.
Physical Characteristics
Dimensions
| 2.05 in. L x 1.40 in. W x 0.57 in. H 52 mm L x 35.5 mm W x 14.6 mm H |
| Weight | 1.1 oz./31 g |
| Optical Resolution | 1280 x 800 pixels |
| Roll | 360° |
| Pitch | ±60° |
| Skew | ±60° |
| Aiming Element | SE4770: 655 nm Laser |
| Illumination Element | SE4770: 1 Hyper Red 660 nm LED |
| Field of View | SE4770: Horizontal: 48°, Vertical: 30° |
| Ambient Light Immunity (from total darkness) | Max 107,639 lux (direct sunlight) |
| Supported 1D Symbologies | Code 39, Code 128, Code 93, Codebar/NW7, Code 11, MSI, UPC/EAN, I 2 of 5, Korean 3 of 5, GSI DataBar, Base 32 (Italian Pharma) |
| Supported 2D Symbologies | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes |
| Supported OCR Symbologies | OCR-A, OCR-B |
| Power | 480 mAh embedded Li-ion battery pack |
| Network Connections | WPAN (Bluetooth) |
| Scanner Support | SE4770 1D/2D standard range imaging engine |
| Pairing | NFC; Tap to Pair |
Performance Characteristics
| User Environment | RoHS Directive 2011/65/EU; Amendment 2015/863 REACH SVHC 1907/2006 |
| Operating Temperature | 32° F to 122° F/0° C to 50° C |
| Storage Temperature | -40° F to 140° F/-40° C to 60° C |
| Humidity | 5% - 95% non-condensing |
| Drop Specification | Multiple 6 ft./1.8 m drops to concrete over the operating temperature range |
| Tumble Specification | 1,000 1.64 ft./0.5 m tumbles |
| Sealing | IEC 60529: IP54 |
| Vibration | Sine 5-2000Hz, 4g peak, 1 hour per axis; Random 20-2000Hz, 6g RMS or 0.04g2/Hz, 1 hour per axis |
| Electrostatic Discharge (ESD) | ±15kVdc air discharge; ±8kVdc contact discharge |
User Interface
| LED | 2 RGB LEDs located at the back side of the device |
| Beeper | Up to 85 dBA @ 10 cm from the back of the device beeper port |
Wireless PAN
| Bluetooth | Class 1 and 2, Bluetooth v5.2 with Bluetooth Low Energy (BLE); Supported profiles: Serial Port Profile (SPP), Human Interface Device Profile (HID), Service Discovery Application Profile (SDAP) |
Decode Ranges (Typical Working Ranges)2
Symbology Resolution | Near/Far |
| Code 39: 3 mil | 3.0 in. / 7.6 cm to 5.8 in. / 14.7 cm |
| Code 128: 5 mil | 2.3 in. / 5.8 cm to 9.8 in. / 24.9 cm |
| PDF417: 5 mil | 3.0 in. / 7.6 cm to 7.9 in. / 20.1 cm |
| PDF 417: 6.67 mil | 2.5 in. / 6.3 cm to 10.1 in. / 25.7 cm |
| DataMatrix: 10 mil | 2.1 in. / 5.3 cm to 11.0 in. / 27.8 cm |
| UPCA (100%) | 1.6 in. / 4.1 cm to 24.9 in. / 63.2 cm |
| Code 128: 15 mil | 2.4 in. / 6.1 cm to 27.8 in. / 70.6 cm |
| Code 39: 20 mil | 1.6 in. / 4.1 cm to 36.1 in. / 91.7 cm |
| QR Code: 20 mil | 1.1 in. / 2.8 cm to 17.5 in. / 44.5 cm |
Warranty
| Subject to the terms of Zebra’s hardware warranty statement, the RS2100 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment. For complete warranty statement, go to www.zebra.com/warranty |
Recommended Services
| Zebra OneCare Essential; Zebra OneCare Select |
Footnotes
1. Device Tracker requires a license. Specifications are subject to change without notice. |
Mobility DNA
| For information on Mobility DNA, visit www.zebra.com/mobilitydna. Mobility DNA features vary by model; a support contract may be required. To learn what solutions are supported, visit: https://developer.zebra.com/mobilitydna |
